Mulchers HM418

Request A Price Click for Price

Key Specs

Overall Width: 83.5 in; 2122 mm

Working Width: 67.2 in; 1707 mm

Length: 53.3 in; 1355 mm

HM418
Change model

Overview

High-performance cutting and mulching of vegetation and overgrowth.

Features At A Glance

Use Mulchers for brush clearing, vegetation management, reclaiming untitled land, environmental maintenance, shredding pruned material and organic waste for biomass production.

Designed for high-performance cutting, and mulching vegetation and undergrowth from typical wooded terrain. Reduces saplings, shrubs and trees into mulched material.

Rugged mulching head processes trees up to 200 mm (8 in) diameter for effective land clearing applications.

Dual speed, axial piston motor provides smooth, efficient performance while delivering optimal torque under changing material loads.

Standard adjustable push frame allows for control of trees for optimal cutting and efficiency. Low profile design improves operator visibility and pin-style segments provide the opportunity to control which section of teeth are cutting, improving tooth life.

Color-coded pressure gauge is standard equipment that provides operator feedback in order to maximize productivity. With green, yellow, and red regions, the operator has indication of the load being applied to the mulcher and if adjustments can be made to maximize productivity in changing material loads.

Hydraulically operated front hood is standard. Linkage is enclosed within mulcher frame on High Flow models. Quick to open and close door allows for finer finished material to be produced from cutting all types of vegetation.

Rear chain guard protection reduces spread of material.

Serrated steps allow for safe and easy access in and out of the cab.

Hinged and lockable service panel allows easy access to hoses. Lockable with your Cat key, the service panel allows easy access to drive train components during service and inspection.

Adjustable and replaceable skid shoes allow operator to control the ground height to accommodate different types of terrain.

Tool Mounted Operation and Maintenance Manual (OMM) Holder

Located inside the lockable service panel and sealed from the elements, this holder includes all of the operation manuals and maintenance guides required for proper operation of the work tool.

Select from Standard Carbide, Rock Resistant, Chisel, and Side Cutter options to configure the C Series Mulcher to any underfoot or vegetation condition.

Product Specifications for HM418

Overall Width	83.5 in 2122 mm
Working Width	67.2 in 1707 mm
Length	53.3 in 1355 mm
Overall Height	58.3 in 1481 mm
Weight	3196.7 lb 1450 kg
Drive Method	Polychain Belt Polychain Belt
Motor	Axial Piston Dual Speed Axial Piston Dual Speed
Required Hydraulics	XHP / XE XHP / XE
Optimal Hydraulic Flow	150-155 L/min (40-41 gpm) 150-155 L/min (40-41 gpm)
Optimal Hydraulic Pressure	200-278 bar (2900-4061 psi) 200-278 bar (2900-4061 psi)
Drum Speed	2140-2210 RPM 2140-2210 RPM
Fixed Teeth per Drum	38 38
Maximum Cutting Diameter	7.9 in 200 mm
Maximum Cutting Depth	4.1 in 105 mm

Product Specifications for HM418

Download Print

Overall Width	83.5 in 2122 mm
Working Width	67.2 in 1707 mm
Length	53.3 in 1355 mm
Overall Height	58.3 in 1481 mm
Weight	3196.7 lb 1450 kg
Drive Method	Polychain Belt Polychain Belt
Motor	Axial Piston Dual Speed Axial Piston Dual Speed
Required Hydraulics	XHP / XE XHP / XE
Optimal Hydraulic Flow	150-155 L/min (40-41 gpm) 150-155 L/min (40-41 gpm)
Optimal Hydraulic Pressure	200-278 bar (2900-4061 psi) 200-278 bar (2900-4061 psi)
Drum Speed	2140-2210 RPM 2140-2210 RPM
Fixed Teeth per Drum	38 38
Maximum Cutting Diameter	7.9 in 200 mm
Maximum Cutting Depth	4.1 in 105 mm
