C0.7 LRC Diesel Engines - Lesser Regulated & Non-Regulated

Industrial Diesel Engines C0.7

Request A Price Find Dealer

Key Specs

Maximum Power
20.5 hp
15.3 kW
Maximum Torque
37.1 lb-ft @ 2400 rpm
50.4 Nm @ 2400 rpm
Emissions
U.S. EPA Tier 4 Interim Equivalent
U.S. EPA Tier 4 Interim Equivalent

Overview

Cat?� C0.7 Industrial Diesel Engines deliver impressive performance throughout a wide speed range with exceptional power density. Their ultra-compact package size and extensive choice of options ensures these engines are ideal for a wide range of small, off road applications. Single-side servicing improves ease of maintenance and lowers overall owner operating costs. Industries and applications powered by C0.7 engines include: Compactors/Rollers, General Industrial, Mobile Earthmoving Equipment, Mobile Light Towers and Turf and Landscaping. C0.7 engines, with ratings: 12.2-15.3 bkW (16.4-20.5 bhp) @ 2800-3600 rpm, meet EPA Tier 4 Interim equivalent emission standards. They are available using U.S. EPA Flexibility and for Europe, and depending on applicable emission standards, may be introduced in other regulated and non-regulated areas.

Features At A Glance

Specifications Standard Equipment

Product Specifications for C0.7

Download Print
Maximum Power 20.5 hp 15.3 kW
Maximum Torque 37.1 lb-ft @ 2400 rpm 50.4 Nm @ 2400 rpm
Rated Speed 2800-3600 rpm 2800-3600 rpm
Minimum Power 16.4 hp 12.2 kW
Emissions U.S. EPA Tier 4 Interim Equivalent U.S. EPA Tier 4 Interim Equivalent
Length 18.9 in 480 mm
Width 14.6 in 371 mm
Height 20.8 in 528 mm
Weight - Net Dry - Basic Operating Engine Without Optional Attachments 156.5 lb 71 kg
Engine Configuration Inline 3, 4-Stroke-Cycle Diesel Inline 3, 4-Stroke-Cycle Diesel
Bore 2.6 in 67 mm
Stroke 2.8 in 72 mm
Displacement 46.4 in³ 0.762 l
Compression Ratio 23.5:1 23.5:1
Aspiration Naturally Aspirated (NA) Naturally Aspirated (NA)
Combustion System Indirect Injection Indirect Injection
Rotation from Flywheel End Counterclockwise Counterclockwise
Aftertreatment - -

C0.7 Standard Equipment

Print

Air Inlet

  • Inlet manifold with choice of inlets.

Control System

  • Alternator 12 volt 14 amp
  • Starter motor 12 volt
  • Glow plug starting aid

Cooling System

  • Belt-driven coolant pump
  • Coolant temperature switch
  • Choice of cooling fans

Flywheel and Flywheel Housing

  • SAE No. 6 1/2 flywheel
  • Choice of SAE No. 5 or standard backplate flywheel housing

Fuel System

  • Fuel injection pump
  • Spin-on fuel filter
  • Electronic Shut-off Solenoid (ESOS)

Lube System

  • Closed circuit breather
  • Spin-on lube oil filter
  • Lube oil pressure switch
  • Lube oil sump

General

  • Cast iron, engine block
  • Cast iron exhaust manifold--side outlet
  • Cold start capability to -20° C (-4° F)
  • Gradeability 35° continuous
  • Paint: Caterpillar yellow, with optional colors available at request
